Home Products Hematology HORIBA ABX Micros ESV 60
HORIBA · Veterinary Hematology

HORIBA ABX Micros ESV 60

The Gold Standard of Veterinary Hematology Testing

A compact, lightweight veterinary hematology analyser built for accuracy across 10 animal species. Uses electronic impedance variation and photometry to deliver reliable CBC results from just 10μL of whole blood — ideal for small clinics and high-volume labs alike.

50 tests/hour
10μL sample
10 species
8/18 parameters
Request a Quote Download Brochure
In Stock — Pan India HORIBA ABX Micros ESV 60 veterinary hematology analyser
ManufacturerHORIBA, Japan
16 kg
Compact & lightweight
50/hr
Test throughput
1,000
Results stored with histograms
10 μL
Whole-blood micro-sample

What Makes It Different

Built for Speed, Precision & Small Sample Volumes

Electronic Impedance Method

Precise cellular identification through electronic impedance variation, the reference method for enumerating RBCs, WBCs and platelets.

Photometric Haemoglobin

Haemoglobin measurement using photometry alongside impedance counting for a complete, accurate cell count profile.

External Barcode Reader

Instant identification of patient samples, QC and reagents — reduces manual entry errors in busy clinics.

Colour Touchscreen

User-friendly LCD colour touch screen with virtual keyboard makes daily operation simple for clinic staff.

USB Data Transfer

Archive results to PC and upload QC target values via USB key — no complex network setup required.

Trusted Japanese Technology

Engineered by HORIBA, Japan — a globally trusted name in precision measurement and diagnostic instrumentation for over 70 years.

Unique Reagent System

Dedicated reagent pack system ensures consistent, accurate results test after test — fully supplied by Stethix Healthcare.

Multi-Species Calibration

10 Animal Species, One Analyser

Dog face
Dog
18 parameters
Cat face
Cat
18 parameters
Horse face
Horse
18 parameters
Rabbit face
Rabbit
8 parameters
Rat face
Rat
8 parameters
Mouse face
Mouse
8 parameters
Pig face
Pig
8 parameters
Monkey face
Monkey
8 parameters
Cow face
Cow
8 parameters
Sheep face
Sheep
8 parameters

Full Specification Sheet

Technical Specifications

Weight16 kg (30.9 lb)
Power Supply100V to 240V — 50Hz to 60Hz
Dimensions43 cm × 36 cm × 36 cm (H×L×D)
PrinterExternal
Throughput50 tests/hour
Data ManagementComplete QC menu, reagent/calibration/maintenance logs, LAN transmission (mono-directional)
Memory1,000 patient results with histograms
ScreenLCD colour touch screen
Sampling ModeOpen tube — 50 tests/hour
8 ParametersRabbit, rat, mouse, pig, monkey, cow, sheep — WBC, RBC, PLT, HGB, HCT, MCV, MCH, MCHC
18 ParametersDog, cat, horse — WBC, LYM#/%, MON#/%, GRA#/%, EOS#/%, RBC, PLT, HGB, MPV, HCT, MCV, MCH, MCHC, RDW
GraphicsPLT, RBC, WBC distribution curves
Blood Volume10 μL (CBC + 4DIFF mode)
Sample Stability48 hours post-draw
IdentificationAlphanumeric, external barcode reader
SpeciesParameterPrecision (CV%)Linearity
CatWBC< 3 (5.5–19.5 ×10³/μL)0–100 ×10³/μL
RBC< 3.5 (5–10 ×10⁶/μL)0–12 ×10⁶/μL
HGB< 3.5 (8–15 g/dL)0–900 g/dL
HCT< 3.5 (24–45%)0–25%
PLT (whole blood)< 8.0 (300–800 ×10³/μL)0–70 ×10³/μL
DogWBC< 4 (6–17 ×10³/μL)0–100 ×10³/μL
RBC< 2.5 (5.5–8.5 ×10⁶/μL)0–10 ×10⁶/μL
HGB< 2.5 (12–18 g/dL)0–900 g/dL
HCT< 2.5 (37–55%)0–25%
PLT< 10.0 (200–500 ×10³/μL)0–70 ×10³/μL
HorseWBC< 3 (5.4–14.3 ×10³/μL)0–100 ×10³/μL
RBC< 2.5 (6.8–12.9 ×10⁶/μL)0–12 ×10⁶/μL
HGB< 2.5 (11–19 g/dL)0–900 g/dL
HCT< 2.5 (32–53%)0–25%
PLT< 10.0 (100–350 ×10³/μL)0–70 ×10³/μL

Keep It Running

Reagents, Controls & Accessories

Micros ESV 60 Reagents

Blood Controls & Calibrators

QC Program (QCP)

Installation & Training

Why Buy the ESV 60 From Stethix Healthcare

Genuine HORIBA Engineering

Built on HORIBA's trusted Japanese precision-measurement technology, refined for veterinary diagnostics worldwide.

On-Site Installation & Training

Our team installs, calibrates and trains your clinic staff to run the analyser confidently from day one.

Reagent Supply, Always

Continuous reagent and consumable supply across Kerala, Telangana, Karnataka, AP and 18+ states.

AMC & After-Sales Support

Annual Maintenance Contracts and responsive service keep your analyser running with minimal downtime.

Ready to Equip Your Clinic With the ESV 60?

Get a personalised quote, installation timeline and AMC options for your veterinary practice — anywhere in Kerala, Telangana, Karnataka, Andhra Pradesh or across India.

WhatsApp for a Quote Call +91 91084 47768
